Overview
Handcrafted since 2008, WA6 (2nd gen) has set the standard for headphone amplifiers in its class. It can drive full-size headphones and in-ear monitors ranging from 8–600 Ohms with ease. WA6 (2nd gen) is an all-tube design, Class-A, transformer-coupled, single-ended triode (SET) amplifier. Under the hood of the all aluminum chassis is the same clean point-to-point wiring and premium quality parts found in our top tier models. WA6 (2nd gen) is an exceptional headphone amplifier for every music lover.
하이라이트
-
Updated to 2nd generation in April 2017
-
2nd gen is a minor update to driver/power tubes from 6v to 13v
-
Tubes: 13DE7 driver/power x 2, 5U4G rectifier x 1
-
폴리테트라플루오로틸렌(PTFE) 튜브 소켓
-
Singled-ended Triode, Class-A
-
변압기 결합형, 지점 간 배선
-
Pseudo-dual power supply
-
RCA input x 1
-
HI / LO headphone impedance switch
-
1/4"(6.3mm) 스테레오 헤드폰 출력(8-600 옴)
-
ALPS potentiometer and power switch
-
양극산화 알루미늄 섀시, 블랙 또는 실버로 제공
-
호환되는 튜브를 사용한 자체 바이어스 [차트]
-
Global voltage (100v–220v) without converter
-
Dimensions: 6"(H), 5½"(W), 13"(D), 13 lbs.
-
미국 뉴욕에서 설계 및 조립
-
3년 제한 보증[자세히 알아보기]
상자에서
-
WA6 (2nd gen) headphone amplifier x 1
-
13DE7 vacuum tube x 2
-
5U4G(5U3C) 정류기 튜브 1개
-
빠른 시작 가이드
-
UPGRADE [learn more]: Woo Audio PHANTOM DAC cable [1m or 2m length] x 1
*AC 전원 코드 및 오디오 케이블은 포함되어 있지 않습니다.
